A 1-D transformation to RGB Colors

The task is to find a way to represent RGB colors from using a single variable $x$. I could use HSV where $h=x$ and set $s$ and $v$ to a constant, that would work, but in HSV $h$ is an angle that goes from 0 to 360, and so small $h$ ($h=\delta$) and and large $h$) ($h=360-\delta$) will give the same RGB value, which is not what you might want.

The key to making this transformation is that it be two way: $x\to RGB$ and $RBG\to x$, and the $RGB\to x$ is the hard part because we want things to be single valued. Since we have 3 colors (RGB), we want a transformation $x\to RGB$ that always has at least one of the 3 colors off. And, we want the colors to wax and wane, in a continuous way. Something like the following seems to work. You can drag around the inside of the black box and it will show you the transformation from $x$, the horizontal scale, to the 3 colors $R$, $G$, $B$. Note that we've defined 6 regions, where the conditions in each region are constant ($R$, $G$, $B$ don't change or change linearly): $I\to x=[0,0.2)$, $II\to x=[0.2,0.3)$, $III\to x=[0.3,0.5)$, $IV\to x=[0.5,0.6)$, $V\to x=[0.6,0.8)$, $VI\to x=[0.8,1.0]$.


R: G: B:
Color:
The code to do this looks like this:
function xtorgb(x) {
  //
  // x goes between 0 and 1
  //
  let r=0, g=0, b=0;
  if (x < 0.2) {
    r = Math.floor( 255*x/0.3 );
    g = 0;
    b = 0;
  }
  else if (x < 0.3) {
    r = Math.floor( 255*x/0.3 );
    g = Math.floor( 255*(x-0.2)/0.3 );
    b = 0;
  }
  else if (x < 0.4) {
    r = Math.floor( 255*(1-(x-0.3)/0.3) );
    g = Math.floor( 255*(x-0.2)/0.3 );
    b = 0;
  }
  else if (x < 0.5) {
    r = Math.floor( 255*(1-(x-0.3)/0.3) );
    g = Math.floor( 255*(x-0.2)/0.3 );
    b = 0;
  }
  else if (x < 0.6) {
    r = Math.floor( 255*(1-(x-0.3)/0.3) );
    g = Math.floor( 255*(1-(x-0.5)/0.3) );
    b = 0;
  }
  else if (x < 0.7) {
    r = 0;
    g = Math.floor( 255*(1-(x-0.5)/0.3) );
    b = Math.floor( 255*(x-0.6)/0.4 );
  }
  else if (x < 0.8) {
    r = 0;
    g = Math.floor( 255*(1-(x-0.5)/0.3) );
    b = Math.floor( 255*(x-0.6)/0.4 );
  }
  else {
    r = 0;
    g = 0;
    b = Math.floor( 255*(x-0.6)/0.4 );
  }
  return {r:r, g:g, b:b}
}
where $x$ is the input and the return is an object, with members $r$, $g$, $b$, like this:
  nc = xtorgb(x);
  r = nc.r;
  g = nc.g;
  b = nc.b;
To turn $(r,g,b)$ into a color of the form "#$ABCDEF$", you can use:
  color = intstocolor(r,g,b);
where the code for that is here:
function intstocolor(r1,r2,r3) {
    s1 = r1.toString(16).toUpperCase();
    if (r1 < 16) s1 = "0"+s1;
    s2 = r2.toString(16).toUpperCase();
    if (r2 < 16) s2 = "0"+s2;
    s3 = r3.toString(16).toUpperCase();
    if (r3 < 16) s3 = "0"+s3;
    let newc = "#"+s1+s2+s3;
    return newc;
}

Now for the reverse transformation. This is a lot easier to code up than you might think. It's just a series of questions asking which of the 3 colors is identically 00, and branching. The flow chart looks like this:

Starting from the top, $G=0?$, this tells us that we are either in region $I$ or region $V-VI$. In region $I$, $R>0$ so if we test on $R=0?$ we will know if we are to the left or right of where $G>0$. If $R=0$, then we are to the right, and the value for $x$ is determined entirely by the value of $B$. If we are to the left, then we use the value of $R$ to determine $x$. If we are in the region where $G>0$, then if $R=0$ we are in region $V$ and again we can use the value for $B$ to determine $x$. If $R>0$ then we are either in region $II$-$III$ where $G$ is increasing, or region $IV$ where $G$ is decreasing, but either way all we need to know if the value for $G$ to determine $x$. Voila. The canvas below shows the color scheme as $x$ increases bottom to top. Click on a color and it will show you the corresponding value of $x$.

The code to implement this is here:
function rgbtox(r,g,b) {
  let x = -1;
  if (g == 0) {
    if (r == 0) x = (0.4*b/255) + 0.6;
    else x = .3*r/255;
  }
  else {
    if (r == 0) x = (0.4*b/255) + 0.6;
    else {
      if (r < 255/3) x = (0.3*(1-g/255)) + 0.5;
      else x = (0.3*g/255) + 0.2;
    }
  }
  return x;
}
Note: the color scheme here increases from red ("coolest") to blue ("hottest"). If you want to change it so that it goes the other way, just interchange $r$ and $b$ in the two routines above (xtorgb and rgbtox).
Drew Baden. Aug 15, 2020
